The C4S features a vandal-proof dome cover and IP66-rated water and dust resistance to protect against all forms of weather and vandalism.
Adaptive Video Technology
Supports 2.4GHz Wi-Fi
True Day/Night, Auto Switch, Infrared Night Vision
IP66 Dust and Water Protection
Optional Wi-Fi and PoE
Supports MicroSD Card
Support Cloud Recording (Optional)
Vandal-Proof Design
(Up to 30 meters)
(Power over Ethernet)
（Up to 128G）
Sensor that processes video while keeping track of how many people walk by, all while using less energy.
More Processing Power
The C4S supports a wired connection as well as a Wi-Fi option, freeing you from the hassle of dealing with cables.
The C4S delivers clear-as-day night vision up to 30 meters. Night vision sensors automatically kick on when it gets dark for continuous security coverage.
See every detail in the best lighting with WDR up to 120db, which automatically controls white balance levels for clearer video and images.
The C4S watches for movement, It will take a picture and send an alert to your smartphone whenever motion is detected.(Need to activate manually)
With multiple storage options, you can choose where to save your recordings.The cameras can even save to all three locations at the same time for added backup in case a camera is damaged or your network crashes.
Encrypted Cloud Storage
EZVIZ NVR
| Model Parameters | |
|---|---|
| Model | CS-C4S-52(W) EFR (4mm) |
| Camera | |
| Image Sensor | 1/3” Progressive Scan CMOS |
| Minimum Illumination | 0.02 lux @(F2.0, AGC ON), 0 lux with IR |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm@ F2.0, Horizontal angle : 90° Diagonal angle 107.5° |
| Lens Mount | M12 |
| Day & Night | IR-cut filter |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Compression | |
| Video Compression | H.264 |
| H.264 Type | Main profile |
| Video Bit Rate | HD, Balance and Smooth bit rate |
| Image | |
| Max. Resolution | 1920×1080 |
| Image setting | Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
| BLC | Support |
| Network | |
| Storage | Support Micro SD card (Max. 128G) |
| Smart Alarm | Motion detection |
| Wi-Fi Pairing | SmartConfig (Wi-Fi One-Key Configuration) |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| General Features | Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Minimum Network Requirements | 2Mbps |
| Wireless Specifications (for Wi-Fi-supported devices) | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps |
| General | |
| Operating Conditions | -30°C ~ 60°C, Humidity 95% or less (non-condensing) |
| Power Supply | DC 12V±10% |
| Power Consumption | Max. 6W (ICR 9W) |
| IR Range | MAX. 30 meters |
| Product Dimensions | 116.2mm × 110mm |
| Packaging Dimensions | 195mm x 140mm x 98mm |
| Weight | 300g |
