By combining 360° horizontal panorama and smart tracking, the C6TC is a Wi-Fi pan-tilt camera that gives full-room coverage and delivers clear 1080p FHD video in rich colors and sharp details.
True Day/Night, Auto Switch, Infrared Night Vision
Supports MicroSD Card
The beauty of this incredible HD pan-tilt camera is that you can place it wherever you want and still see the whole room. The C6TC includes an expansive field-of-view coverage with 340° horizontal, 80° vertical upward and 10° vertical downward rotations.
(Up to 10 meters)
(Up to 128GB)
360° Horizontal FOV
Upon detection of movement, the C6TC automatically captures and tracks the motion while delivering notifications and video recordings in real time.
Sometimes you want a little alone time. Don’t worry, we’ve got you covered. The thoughtfully-designed privacy shutter allows you to turn the lens off whenever you need privacy.
The C6TC is equipped with two powerful infrared lights for illumination up to 10 meters (depending on environment) – large enough to cover just about any room. Switches between day and night modes automatically.
When you are away from home and want to speak to loved ones or pets, there’s two-way talk. Just press the button on the EZVIZ app and the C6TC will help you do the rest.
The C6TC can be integrated into the EZVIZ alarm system. Once an alarm is triggered, the camera will capture a picture and video footage and send them to the device owner.
With multiple storage options, you can choose where to save your recording. The cameras can even save to all three locations at the same time for added backup in case a camera is damaged or your network crashes.
Encrypted Cloud Storage
EZVIZ NVR
Model Parameters | |
---|---|
Model | CS-CV248-A0-32WFR |
Camera | |
Image Sensor | 2 Megapixel 1/3” Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens | 4mm@ F2.2, Diagonal angle: 95° |
PT Angle | Pan: 340°, Tilt: 90° |
Lens Mount | M12 |
Day & Night | IR-cut filter with auto-switching |
DNR | 3D DNR |
WDR | Digital WDR |
Compression | |
Video Compression | H.264 |
H.264 Type | Main profile |
Video Bit Rate | HD, Balanced and Smooth. Adaptive bit rate |
Image | |
Max. Resolution | 1920×1080 |
Image setting | Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
BLC | Support |
Network | |
Storage | Support Micro SD card (Max. 128G) |
Smart Alarm | Motion detection |
Wi-Fi Pairing | SmartConfig (Wi-Fi One-Key Configuration)/AP paring |
Protocol | EZVIZ cloud proprietary protocol |
Interface Protocol | EZVIZ cloud proprietary protocol |
General Features | Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
Minimum Network Requirements | 2Mbps |
Wi-Fi | |
Standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20MHz |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps |
General | |
Operating Conditions | -10°C ~ 55°C, Humidity 95% or less (non-condensing) |
Power Supply | DC 5V±10% |
Power Consumption | Max. 8W |
IR Range | Max. 10 Meters |
Product Dimensions | 100mm x 100mm x 90mm |
Packaging Dimensions | 126mm x 126mm x 155mm |
Weight | 220g |
